Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 120mm -
Fork Suntour XCR
-
Groupset CUES -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Hydroformed, heat-treated 6061-T6 aluminum hardtail frame. Tapered head tube with double-butted top and down tubes. 135mm axle spacing with quick-release dropouts. Internal cable routing. UDH derailleur hanger.
Suspension Fork
SR Suntour SF18 XCR34-Boost, 1.5" tapered, 15x110 thru axle, 120mm travel
Drivetrain
Rear Derailleur
Shimano Cues 10-speed, RD-6000 Shadow Plus
Shift Levers
Shimano Cues 10-speed with optical window
Cassette
Shimano Cues CS-LG3000-10 11-48T
Crank
Shimano Cues 2-piece, FC-U6000-1, 170mm, 32T chainring
Bottom Bracket
Shimano Cues BB-MT501 BSA 73mm
Chain
Shimano Linkglide CN-LG500
Pedals
FPD PC
Wheels
Front Hub
Shimano HB-TC500 Center Lock 32h, 15mm thru-axle
Rear Hub
Shimano FH-TC500, Center lock, 32h, quick release
Rims
Alloy double-wall, pinned seams, 32h w/eyelets
Tires
Kenda Regolith 29 x 2.4" front and rear
Brakes
Brakes
Shimano MT200 Hydraulic 2-piston disc brake with 180mm rotor front and 160mm rotor rear
Cockpit
Stem
Alloy 6061 Forged 40mm reach
Handlebar
Haro Alloy 6061 Pivot MTB riser bar, 780 wide, 20mm rise
Headset
FSA Dozer sealed, tapered 1-1/8" - 1-1/5" (44/56mm)
Seat
Saddle
WTB Volt Medium
Seatpost
Forged alloy micro-adjust pivot seat post
