Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 120mm -
Fork Suntour XCM
-
Groupset CUES -
Suspension Hardtail -
Drivetrain 1 × 9 -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Hydroformed, heat-treated 6061-T6 aluminum hardtail frame. Tapered head tube with double-butted top and down tubes. 135mm axle spacing with quick-release dropouts. Internal cable routing. UDH derailleur hanger.
Suspension Fork
SR Suntour XCM32-Boost 120mm travel; coil with preload; 1.5" tapered, 15x110 thru-axle
Drivetrain
Rear Derailleur
Shimano Cues 9-speedd RD-U4000 Shadow
Shift Levers
Shimano Cues SL-U4000-9R 9-speed with optical window
Cassette
Shimano Cues 11-41T CS-LG500
Crank
Shimano Cues 2-piece, FC-U4000-1, 170mm, 32T chainring
Bottom Bracket
Shimano Cues BSA 73mm, BB-UN101
Chain
Shimano Linkglide CN-LG500
Pedals
FPD PC
Wheels
Front Hub
Shimano HB-TC500 Center Lock 32h, 15mm thru-axle
Rear Hub
Shimano FH-TC500, Center lock, 32h, quick release
Rims
Alloy double-wall, pinned seams, 32h w/eyelets
Tires
Kenda Regolith 29 x 2.4" front and rear
Brakes
Brakes
Shimano MT200 Hydraulic 2-piston disc brake with 180mm rotor front and 160mm rotor rear
Cockpit
Stem
Alloy 6061 Forged 40mm reach
Handlebar
Haro Alloy 6061 Pivot MTB riser bar, 780 wide, 20mm rise
Headset
FPD DOZER tapered 1-1/8" - 1-1/5" FSA (44/56mm)
Seat
Saddle
DDK-250V PHU Leather
Seatpost
Forged alloy micro-adjust pivot seat post
