Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Suspension Rigid -
Motor Bafang 500W hub-drive -
Battery Internal 50 cell, 48V, 672WH -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 Heat treated aluminium twin top tube frame.
Suspension Fork
Full chromoly 1-1/8" - 1-1/5" tapered fork with 3/8" dropouts
Drivetrain
Cassette
36t Alloy Chainring with aluminium chain guard
Crank
3-pc Hollow forged aluminium with tapered square spindle - 170mm
Bottom Bracket
Euro square tapered pedal assist
Chain
KMC 410 Z chain
Pedals
FPD PC 9/16"
Wheels
Front Hub
Sealed bearing, High flange, 36H female axle front hub
Rims
27.5" Alloy 36h, Double Wall
Tires
Kenda "Kwick Seven" 27.5" x 2.4"
Brakes
Brakes
Promax Mechanical Disc Brake, 160mm Rotor
Brake Levers
Promax 2.5 finger
Cockpit
Stem
Baseline forged 48mm reach
Handlebar
Haro 5" Legends 2-piece bar
Grips
Baseline Flangeless
Headset
FSA 1 1/8" X 1.5" Sealed Bearing
Seat
Saddle
Haro Johnny 5 saddle
Seatpost
Alloy, 30.9 x 350mm
Motor & Battery
Motor
Bafang 500w
Battery
Internal 50 cell, 48V, 672WH
Fit data
Geometry
