Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Suspension Rigid -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Full chromoly frame w/ 1-1/8" integrated headtube, mid BB shell, removable brakes mounts & 14mm dropouts. 12.75"CS, 75.5°HT
Suspension Fork
Full chromoly 1 1/8" threadless internally threaded steerer tube & tapered legs. 15mm offset
Drivetrain
Cassette
25t Steel Chainring
Crank
Haro Baseline 3-pc chromoly 8 Spline 165mm
Bottom Bracket
Sealed bearing mid
Chain
Baseline chain
Pedals
Poly platform. Chromoly 9/16" Axle
Wheels
Front Hub
36h alloy sealed, female axle
Rear Hub
Alloy 9t sealed freecoaster rear. 14mm male axle
Rims
20" alloy double-wall rims. 36 holes.
Tires
Haro La Mesa 20 x 2.4"
Brakes
Brakes
Alloy 990 U-Brake
Brake Levers
Haro Baseline two-finger
Cockpit
Stem
Haro Baseline 48mm reach
Handlebar
Haro chromoly, 9" rise 2-piece
Grips
Haro Baseline 163mm flangeless
Headset
Integrated 1-1/8" threadless sealed bearings
Seat
Saddle
Baseline 5° seat/post combo
Seatpost
Aluminium 25.4mm
Fit data
Geometry
