Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 100mm -
Groupset microSHIFT Mezzo, microSHIFT M26 -
Suspension Hardtail -
Motor Bafang 500W hub-drive -
Battery Bafang 48V 13.2Hh 576WH, 13S4P, EVE 2900 cells, UL certified -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 T6 Aluminium; tapered head tube and internal battery. Built-in grid mounting plate
Suspension Fork
100mm travel I Single crown I 32mm Aluminum stanchions
Drivetrain
Rear Derailleur
Microshift RD-M26L
Shift Levers
Microshift TS39-7
Cassette
Shimano mf-TZ500-7SPD 14-28T
Crank
Forged aluminum | 170MM
Bottom Bracket
Square Taper | 73mm | 148mm Spindle I Cadence Sensor
Chain
KMC Z7 | 7SPD
Pedals
9/16" chromoly axle, alloy body
Wheels
Rims
Bafang Alloy 6 Spoke Mag Wheel
Tires
Kenda Krusade 20"X4"
Brakes
Brakes
Rush Dual Piston | Open System | 180mm Rotors | STD Mount
Brake Levers
Radius 2.5 Finger | Sensor Control Cut Off | Reach Adjustment
Cockpit
Stem
Haro Baseline 48mm reach
Handlebar
Haro Baseline 2-piece 9.5"
Headset
1-1/8" - 1-1/5" tapered internal headset
Seat
Saddle
Haro Cafe
Motor & Battery
Motor
Bafang 500W. Class 2, 500W/20MPH, five levels of pedal assist
Battery
Bafang 48V 13.2Hh 576WH, 13S4P, EVE 2900 cells, UL certified
Fit data
Geometry
