Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 100mm -
Groupset microSHIFT Mezzo, microSHIFT M26 -
Suspension Hardtail -
Motor Bafang 750W hub-drive -
Battery 48V | 13.2AH | 13S4P | 3300mAh | BAK | UL certified -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 T6 Aluminium; tapered head tube and internal battery; Built in Grid mounting plate
Suspension Fork
100mm travel I Triple crown I Aluminum 32mm stanchions
Drivetrain
Rear Derailleur
Microshift RD-M26L
Shift Levers
Microshift TS39-7
Cassette
42T Alloy Chainring Alloy Guard
Crank
Forged aluminum | 170MM
Bottom Bracket
Square Tapper | 73mm | 148mm Spindle I Cadence Sensor
Chain
KMC Z7 | 7SPD
Pedals
9/16" Cro-Mo Axle, Alloy Body
Wheels
Rims
Bafang Alloy 6 Spoke Mag Wheel
Tires
Kenda Krusade 20"X4"
Brakes
Brakes
Rush Dual Piston | Open System | 180mm Rotors | STD Mount
Brake Levers
Radius 2.5 Finger | Sensor Control Cut Off | Reach Adjustment
Cockpit
Stem
Haro Baseline 48mm EXT.
Handlebar
Haro Baseline 9.5"
Grips
Dual locking 135mm Velo Grips
Headset
1-1/8" - 1-1/5" tappered internal headset
Seat
Saddle
Haro Cafe
Motor & Battery
Motor
Bafang 750W. Class 2, 750W/20MPH
Battery
48V | 13.2AH | 13S4P | 3300mAh | BAK | UL certified
Fit data
Geometry
