Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset microSHIFT Advent -
Suspension Hardtail -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 aluminum | Rider-tuned geometry | 68mm threaded BSA BB shell | Flat Mount
Suspension Fork
Suntour SF20 NEX HLO-DS | 63mm travel | Hydraulic Lockout | Post-mount
Rear Shock
N/A
Drivetrain
Rear Derailleur
Microshift RD-M619M
Front Derailleur
N/A
Shift Levers
Microshift SL-M819R-9 | 1 x 9-speed
Cassette
Wide-range | 9-speed | 11-40T
Crank
3-pc aluminum | 42T single chainring | 104mm BCD | Dual aluminum chainguards | 170 / 175mm
Bottom Bracket
Threaded BSA 68mm BB shell | 118mm spindle | Sealed cartridge
Chain
KMC X9 | 9-speed | NP/NP with missing link
Pedals
VP | 990S | Nylon body with steel cages | Chromoly axles
Wheels
Front Hub
KT-68 alloy 28H | Cassette rear hub | Front & rear quick release
Rear Hub
KT-68 alloy 28H | Cassette rear hub | Front & rear quick release
Rims
Haro 700c | 19mm inner width | 28h | Alloy double wall | Disc-brake specifc
Tires
Kenda Kwick Bitumen, 700 x 38c
Brakes
Brakes
Flat mount | Mechanical disc | IS 6-bolt rotors | F: 180mm R: 160mm
Brake Levers
Tektro alloy hydraulic | 3-finger
Cockpit
Stem
Haro Maverick Stem | Alloy | Positive Positioning | 7° rise | 15.5": 70mm; 17.5" & 19": 90mm; 21 & 23": 100mm
Handlebar
Haro Alloy | 25mm rise | 31.8mm | 9° sweep | 620mm / 640mm
Headset
Haro Precision Plus | 1-1/8" threadless | Internal | For 50mm OD headtube
Seat
Saddle
Haro | Dual-sport tuned padding | Weather-resistant cover
Seatpost
Haro aluminum | Micro-adjust | 27.2mm x 350mm | Zero-offset | 2-bolt design
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.52 mm | 1.5 mm | 1.47 mm | 1.49 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 645 mm | 655 mm | 671 mm | 686 mm | 697 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 72 mm | 73 mm | 72 mm | 72 mm | 72 mm |
| Stack | 588 mm | 597 mm | 607 mm | 616 mm | 630 mm |
| Reach | 387 mm | 394 mm | 406 mm | 418 mm | 424 mm |
| Top Tube Length | 569 mm | 579 mm | 594 mm | 609 mm | 619 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 394 mm | 445 mm | 483 mm | 533 mm | 584 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm | 155 mm |
| Chainstay Length | 439 mm | 439 mm | 439 mm | 439 mm | 439 mm |
| Wheelbase | 1077 mm | 1087 mm | 1103 mm | 1118 mm | 1129 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 737 mm | 762 mm | 781 mm | 809 mm | 841 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm | 199 cm |
Model Overview
Westlake MicroShift is part of the Haro Westlake model. 4 bikes variations carry this model name so far.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2023 for 789$. Comparing the average cost of a Crosscountry bike to this one, you will see that Westlake MicroShift price is 141.44% lower.
Westlake MicroShift components
Fork
This bike has the Suntour NEX fork installed. The fork’s travel is 63mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
When it comes to wheels, the Westlake MicroShift bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. Haro Westlake MicroShift is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
