Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork Zoom
-
Groupset Deore, Shimano -
Suspension Hardtail -
Motor Shimano 250W 60Nm mid-drive -
Battery BMZ V10, 725Wh -
Drivetrain 1 × 10 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alloy 6061 HT, TPR, integrated battery
Suspension Fork
Zoom Vaxa 32S 868S AMS HLO, 120mm
Drivetrain
Rear Derailleur
Shimano Deore RDM 4120, 10 speed
Shift Levers
Shimano Deore SLM4100, 1×10
Crank
Shimano FCE8000, 34/175mm
Chain
KMC, x10e
Pedals
Wellgo, M272T DU
Wheels
Front Hub
HBC Pro, 15x110mm
Rear Hub
HBC Pro, 12x148mm
Rims
ERX, 32h
Tires
Schwalbe Nobby Nic Performance, 29×2.6”
Brakes
Brakes
Tektro HDM280, 180/180mm
Cockpit
Stem
HBC Pro R-Film, 50-70/31.8mm
Handlebar
HBC Pro R-Film, 760/31.8mm
Headset
Neco, H385E
Seat
Saddle
HBC, VL-4125
Seatpost
HBC Pro R-Film, 350-400/31.6mm
Motor & Battery
Motor
Shimano, STEPS DUE7000
Battery
BMZ V10, 725Wh
