helkama XE10L 10sp 27.5” EP6 2025
2025 E-bike
Estimate price |
4,071$
Weight | 24.4 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Groupset Deore -
Motor Shimano hub-drive -
Battery Shimano EN805L -
Brakes Shimano Deore Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Drivetrain
Shift Levers
Shimano Deore SL- M5130
Crank
Shimano FC-EM600 34H, 170mm
Chain
KMC
Wheels
Rims
Mach1 Trucky 40-584 36R
Tires
Schwalbe Nobby Nic Performance
Brakes
Brakes
Shimano MT410 hydraulic disc brake 180mm
Brake Levers
Shimano
Cockpit
Stem
Fixed 50 mm
Handlebar
Aluminium 35/780 mm
Seat
Saddle
Selle Royal Essenza Athletic
Seatpost
30,9 x 350 mm
Motor & Battery
Motor
Shimano
Battery
Shimano EN805L
Charger
Shimano E8004
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 165 | 18" |
|---|---|---|
| Stack Reach Ratio | 1.615 mm | 1.58 mm |
| Bottom Bracket Height | 295 mm | 295 mm |
| Front Center | 731 mm | 750 mm |
| Rake | 50 mm | 50 mm |
| Trail | 97 mm | 97 mm |
| Stack | 670.2 mm | 679.4 mm |
| Reach | 415 mm | 430 mm |
| Top Tube Length | 594.6 mm | 612 mm |
| Seat Tube Angle | 75 ° | 75 ° |
| Seat Tube Length | 420 mm | 460 mm |
| Head Tube Angle | 67 ° | 67 ° |
| Head Tube Length | 130 mm | 140 mm |
| Chainstay Length | 455 mm | 455 mm |
| Wheelbase | 1179 mm | 1198 mm |
| Bottom Bracket Drop | 60 mm | 60 mm |
| Wheels | 27" | 27" |
