hepha City 7 Long Range 2024
2024 E-bike
Estimate price |
3,784$
Weight | 28 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Nexus -
Suspension Hardtail -
Motor 250W 100Nm hub-drive -
Battery HEPHA BT-700B (708Wh) -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy Premium
Suspension Fork
Suntour SF19 NEX-25-C NLO DS, TRAVEL:63mm
Drivetrain
Shift Levers
Shimano / SL-C7000-5 / Nexus
Cassette
Gates / CDX / BCD104, 42T, CL=45.5MM
Wheels
Front Hub
KT-TZ0F / KT-TZYR
Rims
Alex Rims / R25-1R / 27.5" / 584×25
Tires
Kenda / K1052 / 27.5" x 2.2"
Brakes
Brakes
Shimano BR-MT200
Brake Levers
Shimano BL-MT200
Cockpit
Stem
Satori UP2+ / Adjustable Stem / 90mm
Handlebar
Alloy 6061 / Width 660mm / Barbore: 31.8mm
Grips
DDK D2400-1 92mm / 130mm
Seat
Saddle
Selle Royal Vivo 7823 BLACK COREL
Seatpost
Alloy Seat Post, 31.6x300mm
Motor & Battery
Motor
HEPHA P101C (100 Nm / 250 W / 25 km/h)
Battery
HEPHA BT-700B (708Wh)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.462 mm | 1.458 mm | 1.462 mm |
| Front Center | 562 mm | 677 mm | 792 mm |
| Rake | 43 mm | 43 mm | 43 mm |
| Trail | 151 mm | 170 mm | 121 mm |
| Stack | 560 mm | 684 mm | 747 mm |
| Reach | 383 mm | 469 mm | 511 mm |
| Top Tube Length | 544 mm | 605 mm | 665 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 450 mm | 500 mm | 550 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 160 mm | 170 mm | 180 mm |
| Chainstay Length | 484 mm | 484 mm | 484 mm |
| Wheelbase | 1039 mm | 1155 mm | 1270 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Wheels | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
