Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 120mm -
Fork Fox Performance Float 34
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Shimano Deore Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
Fox Float 34 Performance Series, Step-Cast, Grip, 120mm, 29’, 110x15
Drivetrain
Rear Derailleur
Shimano Deore, M6100, Shadow Plus
Shift Levers
Shimano Deore, M6100
Cassette
Shimano Deore, M6100, 10-51T
Crank
Shimano Deore M6120 24mm spindle, 30t Alloy Ring
Bottom Bracket
Shimano SM BB52
Chain
KMC X12
Chain Guide
Ibis Top Guide
Wheels
Rims
Ibis 933 Aluminum Rims, Ibis Hubs
Tires
Maxxis DHR2 29" x 2.4" Exo TR / Maxxis Dissector 29" x 2.4" Exo TR (rear)
Brakes
Brakes
Shimano Deore, 2 Piston
Cockpit
Stem
Ibis 31.8mmS–M: 40mm, L–XL: 50mm
Handlebar
Ibis Aluminum, 780mm
Grips
Lizard Skins Strata Single Clamp
Headset
Cane Creek 40: IS 41/28.6 upper, IS 52/40 lower
Seat
Saddle
WTB Silverado Fusion CrMo 142
Seatpost
KS Vantage DropperS: 110-140mm, M-XM:140-170mm, L-XL: 180-210mm
