Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 160mm -
Travel Rear 147mm -
Fork Marzocchi Bomber Z1 Coil
-
Groupset GX Eagle, NX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
Marzocchi Bomber Z1 Coil, 160mm, 44mm offset, 29”, 110x15mmMedium spring installed. More info here.
Rear Shock
Marzocchi Bomber Air, 210 x 55
Drivetrain
Rear Derailleur
SRAM GX Eagle
Shift Levers
SRAM NX Eagle
Cassette
SRAM XG 1275 10-52 12 speed
Crank
SRAM NX Eagle DUB, 30T
Bottom Bracket
Threaded (73mm English threaded)
Chain
SRAM NX Eagle
Wheels
Rims
Blackbird Send Alloy (Send I front, Send II rear) / 29" / Ibis Hubs
Tires
Maxxis Assegai 29" x 2.5" EXO+ casing, 120tpi / Maxxis DHR II 29" x 2.4" EXO+ casing, 60tpi
Brakes
Brakes
SRAM G2 R, 4 piston
Cockpit
Stem
Ibis 31.8mmS/M: 40mm, L/XL: 50mm
Handlebar
Ibis Aluminum, 780mm
Grips
Lizard Skin Charger
Headset
ZS44 upper / ZS56 lower
Seat
Saddle
WTB Silverado, 142mm
Seatpost
KS Rage-i DropperS: 125mm, M: 150mm, L/XL: 170mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.422 mm | 1.354 mm | 1.324 mm | 1.297 mm |
| Bottom Bracket Height | 341 mm | 341 mm | 341 mm | 341 mm |
| Front Center | 752 mm | 783 mm | 804 mm | 829 mm |
| Rake | 43 mm | 43 mm | 43 mm | 42 mm |
| Trail | 114 mm | 114 mm | 114 mm | 114 mm |
| Stack | 613 mm | 620 mm | 629 mm | 642 mm |
| Reach | 431 mm | 458 mm | 475 mm | 495 mm |
| Top Tube Length | 573 mm | 603 mm | 632 mm | 655 mm |
| Seat Tube Angle | 77 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 368 mm | 380 mm | 432 mm | 483 mm |
| Head Tube Angle | 64.9 ° | 64.9 ° | 64.9 ° | 64.9 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1185 mm | 1216 mm | 1237 mm | 1262 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm | 30 mm |
| Standover Height | 705 mm | 750 mm | 750 mm | 760 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
