Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 160mm -
Travel Rear 150mm -
Fork Marzocchi Bomber Z1
-
Groupset Deore -
Suspension Full -
Brakes Shimano Deore Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 173cm
MD
169cm - 180cm
MD/LG
175cm - 186cm
LG
180cm - 192cm
XL
188cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon front and rear triangle
Suspension Fork
Marzocchi Bomber Z1, 160mm, 29”, 110x15mm
Rear Shock
Fox Float X, Factory Series, 2-Pos Adj. w/EVOL, 230mm x 60mm
Drivetrain
Rear Derailleur
Shimano Deore, M6100, Shadow Plus
Shift Levers
Shimano Deore, M6100
Cassette
Shimano Deore, M6100, 10-51T
Crank
Shimano Deore M6120 24mm spindleS–M: 165mm, XM–XL: 170mm
Bottom Bracket
Threaded BB (73mm BSA)
Chain
KMC X12
Wheels
Rims
Blackbird Send Alloy, 32 Hole, Ibis Logo HubsS–M, F: Send I 29" R: Send II 27.5"XM–XL, F: Send I 29" R: Send II 29"
Tires
Front: Maxxis DHF, 29" x 2.5", Exo+, Rear: Maxxis DHR II, Exo+S–M: 27.5" x 2.5", XM–XL: 29" x 2.5"
Brakes
Brakes
Shimano Deore, M6120, 4-Piston
Cockpit
Stem
Ibis 31.8mmS–M: 40mm, XM–XL: 50mm
Handlebar
Ibis Hi Fi, 31.8mm, 800mm
Grips
Lizard Skins Strata Single Clamp
Headset
ZS44 upper / ZS56 lower
Seat
Saddle
WTB Silverado Fusion CrMo 142
Seatpost
KS Rage-i Dropper 34.9mmS: 125mm, M: 150mm, XM: 170mm, L–XL: 190mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.413 mm | 1.364 mm | 1.324 mm | 1.271 mm | 1.211 mm |
| Bottom Bracket Height | 338 mm | 341 mm | 344 mm | 349 mm | 350 mm |
| Front Center | 762 mm | 786 mm | 815 mm | 849 mm | 890 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 130 mm | 130 mm | 130 mm | 130 mm | 130 mm |
| Stack | 616 mm | 622 mm | 633 mm | 643 mm | 654 mm |
| Reach | 436 mm | 456 mm | 478 mm | 506 mm | 540 mm |
| Top Tube Length | 578 mm | 605 mm | 630 mm | 655 mm | 685 mm |
| Seat Tube Angle | 77 ° | 76.5 ° | 76.5 ° | 77 ° | 77.5 ° |
| Seat Tube Length | 395 mm | 400 mm | 415 mm | 457 mm | 477 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 85 mm | 95 mm | 110 mm | 125 mm | 140 mm |
| Chainstay Length | 435 mm | 435 mm | 436 mm | 438 mm | 440 mm |
| Wheelbase | 1195 mm | 1219 mm | 1249 mm | 1286 mm | 1329 mm |
| Bottom Bracket Drop | 36 mm | 33 mm | 30 mm | 27 mm | 24 mm |
| Standover Height | 693 mm | 734 mm | 757 mm | 772 mm | 784 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 162 cm | 169 cm | 175 cm | 180 cm | 188 cm |
| Rider Max Height | 173 cm | 180 cm | 186 cm | 192 cm | 199 cm |
