Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 45mm -
Fork Zoom
-
Groupset Tourney -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Cross / Trekking 28, AL6061-T4 / T6, hydroforming, internal gear cables
Suspension Fork
ZOOM 141D AMS, alloy, 45mm, adjustable preload
Drivetrain
Rear Derailleur
Shimano RD-TX800
Front Derailleur
Shimano FD-TY710-TS
Shift Levers
Shimano ST-EF505
Cassette
Shimano CS-HG31, 11-32T
Crank
Shimano FC-TY301, 48-38-28T
Bottom Bracket
Shimano BB-UN101
Chain
KMC Z8
Wheels
Front Hub
Shimano HB-TX505
Rear Hub
Shimano FH-TX500-8
Rims
Cross X-6, 622-21 x 20.5mm
Tires
Kenda K935, 42-622 (700x40C)
Brakes
Brakes
Shimano BR-MT200 / ST-EF505, hydraulic, 160/160 mm
Cockpit
Stem
id-Project aluminum, 25.4 mm
Handlebar
id-Project riser bar aluminum, 660 mm
Seat
Saddle
Sell ??Royal RVS Lancia
Seatpost
id-Project aluminum, 30.9 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 42cm | 46cm | 50cm | 54cm | 58cm |
|---|---|---|---|---|---|
| Front Center | 639 mm | 639 mm | 651 mm | 661 mm | 677 mm |
| Top Tube Length | 580 mm | 580 mm | 590 mm | 600 mm | 615 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 420 mm | 460 mm | 500 mm | 540 mm | 580 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 120 mm | 120 mm | 130 mm | 150 mm | 170 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1084 mm | 1084 mm | 1096 mm | 1105 mm | 1121 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
