Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 45mm -
Fork Zoom
-
Groupset Tourney -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Cross / Trekking 28, AL6061-T4 / T6, hydroforming, internal gear cables
Suspension Fork
ZOOM 141D AMS, alloy, 45mm, adjustable preload
Drivetrain
Rear Derailleur
Shimano RD-TX800
Front Derailleur
Shimano FD-TY710-TS
Shift Levers
Shimano ST-EF505
Cassette
Shimano CS-HG31, 11-32T
Crank
Shimano FC-TY301, 48-38-28T
Bottom Bracket
Shimano BB-UN101
Chain
KMC Z8
Wheels
Front Hub
Shimano HB-TX505
Rear Hub
Shimano FH-TX500-8
Rims
Cross X-6, 622-21 x 20.5mm
Tires
Kenda K935, 42-622 (700x40C)
Brakes
Brakes
Shimano BR-MT200 / ST-EF505, hydraulic disc brakes, 160/160 mm
Cockpit
Stem
id-Project aluminum, 25.4 mm
Handlebar
id-Project riser bar aluminum, 660 mm
Seat
Saddle
Sell ??Royal RVS Lancia
Seatpost
id-Project aluminum, 30.9 mm
Fit data
Geometry
