Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 45mm -
Fork Zoom
-
Groupset Tourney, Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Shimano Deore Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Hardtail Touring, AL6061-T4/T6, hydroforming, internal cable routing
Suspension Fork
ZOOM 141D, 45 mm, adjustable preload
Drivetrain
Rear Derailleur
Shimano Altus, RD-M310
Front Derailleur
Shimano Tourney FD-TY601
Shift Levers
Shimano ST-EF505
Cassette
Shimano CS-HG31, 11-32T
Crank
Shimano FC-TY301, 48-38-28T, 170 mm
Bottom Bracket
Shimano BB-UN101
Chain
KMC Z8.3
Wheels
Front Hub
Shimano DH-3D37, Hub dynamo
Rear Hub
Shimano FH-QC300
Rims
Mach1 KARMA, 21-622
Tires
Schwalbe Range Cruiser, K-Guard, 47-622
Brakes
Brakes
Shimano BR-M200 / BL-M505 hydraulic disc brakes, 180/160 mm
Cockpit
Stem
ID-Project AS-831, adjustable, 31.8 mm, 90 mm
Handlebar
ID-Project Riser Bar HB-RB11L, 640 mm
Grips
Herrmans Lockable Grip Line
Seat
Saddle
Selle Royal Premium Essenza
Seatpost
ID-Project SPDC2, 30.9 mm
Fit data
Geometry
