Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 45mm -
Fork Zoom
-
Groupset Tourney, Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Trekking 28, AL6061-T4/T6, hydroforming, internal shifting cables
Suspension Fork
ZOOM 141D, 45 mm, 25.4 mm
Drivetrain
Rear Derailleur
Shimano Altus RD-M310
Front Derailleur
Shimano Altus FD-M313
Shift Levers
Shimano ST-EF505
Cassette
Shimano CS-HG31, 11-13-15-18-21-24-28-32T
Crank
Shimano FC-TY301, 48-38-28T, 170mm
Bottom Bracket
Shimano BB-UN100
Chain
KMC Z8
Wheels
Front Hub
Shimano DH-3D37, Hub dynamo
Rear Hub
Shimano FH-QC300
Rims
Mach1 KARMA, 21-622
Tires
Schwalbe Range Cruiser, K-Guard, 47-622
Brakes
Brakes
Shimano BR-MT200 / ST-EF505, Disc 160/160 mm
Cockpit
Stem
ID-Project AS-831, adjustable, 31.8 mm, 90 mm
Handlebar
ID-Project Riser Bar HB-RB11L, 640 mm
Grips
Herrmans Lockable Grip Line
Seat
Saddle
Selle Royal Premium Essenza
Seatpost
ID-Project, 30.9 mm SP-602
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 42cm | 46cm | 50cm | 54cm |
|---|---|---|---|---|
| Front Center | 642 mm | 642 mm | 652 mm | 663 mm |
| Top Tube Length | 580 mm | 580 mm | 590 mm | 600 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 420 mm | 460 mm | 500 mm | 540 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 140 mm | 140 mm | 140 mm | 160 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1087 mm | 1087 mm | 1097 mm | 1108 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm | 50 mm |
| Wheels | 700 | 700 | 700 | 700 |
