Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 45mm -
Fork Zoom
-
Groupset Tourney, Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Trekking 28, AL6061-T4/T6, hydroforming, internal shifting cables
Suspension Fork
ZOOM 141, 45 mm, preload
Drivetrain
Rear Derailleur
Shimano Altus RD-M310
Front Derailleur
Shimano FD-M313
Shift Levers
Shimano ST-EF505
Cassette
Shimano CS-HG31, 11-13-15-18-21-24-28-32T
Crank
Shimano FC-TY301, 48-38-28T, 170mm
Bottom Bracket
Shimano BB-UN100
Chain
KMC Z8
Wheels
Front Hub
Shimano DH-3D37, Dynamo hub, center lock
Rear Hub
Shimano FH-TX505
Rims
Cross X-6, 21-622
Tires
Kenda K935 Khan, reflective 40-622
Brakes
Brakes
Shimano BR-MT200/ST-EF505, Hydraulic disc breaks 160/160 mm
Cockpit
Stem
ID-Project, AS-832, 90mm, 31.8, adjustable angle
Handlebar
ID-Project Riser Bar, 640 mm, HB-RB11L
Seat
Saddle
Sportourer FLX Lady gel flow 3-Zone-Comfort
Seatpost
ID-Project, 30.9 mm SP-602
Fit data
Geometry
