Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Fork RST VOLANT -
Groupset Altus -
Suspension Hardtail -
Motor Shimano 250W 40Nm mid-drive -
Battery Shimano STEPS battery (carrier) BT-E6000, 36V, 418Wh (11.6Ah) -
Drivetrain 1 × 8 -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Pedelec 28, AL6061-T4/T6, Shimano STEPS, hydroforming, internal brake and cables
Suspension Fork
RST Volant-T, 60mm, adjustable preload
Drivetrain
Rear Derailleur
Shimano Altus RD-M310
Shift Levers
Shimano STEPS switch SW-E6010-L / Shimano Altus SL-M310R
Cassette
Shimano CS-HG31-8, 11-34T
Crank
Shimano STEPS FC-E5000/ SM-CRE50, 38T, 170 mm
Bottom Bracket
STEPS, press-fit
Chain
KMC Z8
Wheels
Front Hub
Shimano HB-TX505
Rear Hub
Shimano FH-TX505
Rims
Mach1 640 Disc, 622*21C
Tires
Kenda K 198, reflective, K- Shield 47-622
Brakes
Brakes
Shimano BR-MT200/BL-M201, hydraulic disc brakes, 180/180 mm
Cockpit
Stem
ID - Project, alloy, adjustable angle, diameter 31.8 mm
Handlebar
ID - Project, alloy riser bar, 640 mm
Grips
Herrmans Comfort
Seat
Saddle
Selle Royal Moody RVS
Seatpost
ID - Project, 31.9 mm
Motor & Battery
Motor
Shimano STEPS center drive unit DU-E5000, 36V, 250W, 40Nm
Battery
Shimano STEPS battery (carrier) BT-E6000, 36V, 418Wh (11.6Ah)
Fit data
Geometry
