Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Fork RST VOLANT -
Groupset CUES -
Suspension Hardtail -
Motor Shimano 250W 40Nm mid-drive -
Battery Shimano STEPS BT-E8014, 36V, 11.6Ah, 418Wh -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eTouring, AL6061-T4/T6, Shimano STEPS, hydroforming, internal brake and cables
Suspension Fork
RST Volant-T, 60 mm, lockout, adjustable preload
Drivetrain
Rear Derailleur
Shimano Cues RD-U4000 GS
Shift Levers
Shimano STEPS SC-E5000 switch / Shimano Cues SL-U4000-9R
Cassette
Shimano Cues CS-LG300-9, 11-36T
Crank
Shimano STEPS FC-E5010, 38T
Bottom Bracket
STEPS, press-fit
Chain
Shimano CN-LG500
Wheels
Front Hub
Shimano HB-TX505
Rear Hub
Shimano TX505-9
Rims
Cross X-6 Disc, 622-21
Tires
Kenda 47-622 (700x45C) K1172
Brakes
Brakes
Shimano BR-MT200/BL-M201, hydraulic disc brakes, 180/180 mm
Cockpit
Stem
ID - Project, alloy, adjustable angle, diameter 31.8 mm
Handlebar
ID - Project, alloy riser bar, 640 mm
Seat
Saddle
Selle Royal Premium Moderate VLS, New Essenza
Seatpost
ID - Project, 31.9 mm
Motor & Battery
Motor
Shimano STEPS DU-E5000, 36V, 250W, 40Nm
Battery
Shimano STEPS BT-E8014, 36V, 11.6Ah, 418Wh
Fit data
Geometry
