Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Fork RST VOLANT -
Groupset Deore, CUES -
Suspension Hardtail -
Motor Shimano 250W 60Nm mid-drive -
Battery Shimano BT-E8010, 504Wh (14Ah) -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eTouring, AL6061-T4/T6, Shimano STEPS, hydroforming
Suspension Fork
RST Volant-T, 60 mm, 30 mm, Coil
Drivetrain
Rear Derailleur
Shimano CUES RD-U4000 Shadow
Shift Levers
Shimano STEPS SW-E7000-L/ Shimano Deore SL-T6000-R
Cassette
Shimano CS-LG300-9, 11-36T
Crank
Shimano STEPS FC-E6100 / SM-CRE61 SCG, 38T
Bottom Bracket
STEPS, press-fit
Chain
Shimano CN-LG500
Wheels
Front Hub
Shimano HB-QC300
Rear Hub
Shimano FH-QC300
Rims
Mach1 640 Disc, 21C-622
Tires
Schwalbe Land Cruiser Plus, PunctureGuard, 50-622
Brakes
Brakes
Shimano BR-MT200/BL-MT201, Hydraulic Disc Breaks 180/180 mm
Cockpit
Stem
Ergotec Octopus 2 Ahead, verstellbar, 31.8 mm, 75/105 mm (Safety Level 4)
Handlebar
Ergotec Ladytown, 620 mm (Safety Level 4)
Seat
Saddle
Selle Royal Premium Essenza
Seatpost
Ergotec Atar, 31.6 mm (Safety Level 4)
Motor & Battery
Motor
Shimano STEPS DU-E6100, 60Nm, sportive
Battery
Shimano BT-E8010, 504Wh (14Ah)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 50cm | 54cm |
|---|---|---|---|
| Front Center | 655 mm | 665 mm | 675 mm |
| Top Tube Length | 580 mm | 590 mm | 600 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 460 mm | 500 mm | 540 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 190 mm | 190 mm | 190 mm |
| Chainstay Length | 475 mm | 475 mm | 475 mm |
| Wheelbase | 1123 mm | 1133 mm | 1143 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" |
