Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Fork RST VITA -
Groupset CUES -
Suspension Hardtail -
Motor Shimano 600W 85Nm mid-drive -
Battery Shimano STEPS BT-EN606, 630Wh, Semi integrated -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eTREKKING semi integrated, Aluminium
Suspension Fork
RST Vita TNL, 60 mm, 28.6 mm, Coil, Lock Out
Drivetrain
Rear Derailleur
Shimano CUES RD-U6000 Shadow Plus
Shift Levers
Shimano STEPS SW-EN600-L / Shimano CUES SL-U6000-10
Cassette
Shimano CS-LG400-10, 11-43T
Crank
Shimano STEPS FC-EM600 / CR-ET600 SCG, 38T
Bottom Bracket
STEPS, press-fit
Chain
Shimano CN-LG500
Wheels
Front Hub
Shimano HB-QC400
Rear Hub
Shimano FH-QC400
Rims
Mach1 640 Disc, 21C-622
Tires
Schwalbe Energizer Plus Tour, GreenGuard, 50-622
Brakes
Brakes
Shimano BR-MT200 / BL-MT201, Disc 180/180 mm
Cockpit
Stem
Ergotec Octopus 2 Ahead, adjustable, 31.8 mm
Handlebar
Ergotec Low Riser, 720 mm
Grips
Herrmans Lockable Grip Line
Seat
Saddle
Selle Royal Premium Essenza
Seatpost
Ergotec Atar, 31.6 mm
Motor & Battery
Motor
Shimano STEPS DU-EP600 center unit, 85Nm
Battery
Shimano STEPS BT-EN606, 630Wh, Semi integrated
Fit data
Geometry
