Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 60mm -
Fork RST VOLANT
-
Groupset Nexus -
Suspension Hardtail -
Motor Shimano 600W 85Nm mid-drive -
Battery Shimano STEPS BT-EN605, semi integrated -
Drivetrain Internally Geared Hub -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
e-CITY Semi-Integrated, AL6061-T4/T6
Suspension Fork
RST Volant-T, 60 mm, adjustable preload
Drivetrain
Shift Levers
Shimano STEPS SW-EN600-L / Shimano Nexus SL-C7000-5
Cassette
Shimano CS-C7000, 27T
Crank
Shimano STEPS FC-EM600 / SM-CRE61 w/o CG, 38T
Bottom Bracket
STEPS, press-fit
Chain
Shimano CN-HG71
Wheels
Front Hub
Shimano HB-QC300
Rear Hub
Shimano Nexus 5 SG-C7000-5D
Rims
Mach1 Traxx 640 Disc, 21C-622
Tires
Schwalbe Energizer Active Plus PunctureGuard, 50-622
Brakes
Brakes
Shimano BR-MT200/BL-MT201, Hydraulic Disc Breaks 180/180 mm
Cockpit
Stem
Ergotec Octopus 2 Ahead, adjustable, 31.8 mm, 90/110 mm
Handlebar
Ergotec Ladytown, 620 mm (Safety Level 4)
Grips
Herrmans Airo Comfort
Seat
Saddle
Selle Royal Premium Essenza
Seatpost
Ergotec Atar, 31.6 mm (Safety Level 4)
Motor & Battery
Motor
Shimano STEPS DU-EP600 center unit, 85Nm, sport
Battery
Shimano STEPS BT-EN605, semi integrated
Fit data
Geometry
