Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 60mm -
Fork RST VOLANT
-
Groupset Nexus -
Suspension Hardtail -
Motor Shimano 60Nm mid-drive -
Battery Shimano BT-E8010, 504Wh (14Ah) -
Drivetrain Internally Geared Hub -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
e-CITY Semi-Integrated, AL6061-T4/T6
Suspension Fork
RST Volant-T, 60 mm, adjustable preload
Drivetrain
Shift Levers
Shimano STEPS (SW-E7000-L) / Shimano Nexus (SL-C7000-5)
Cassette
Shimano CS-C7000, 27T
Crank
Shimano STEPS FC-E6100/ SM-CRE61, 38T
Bottom Bracket
STEPS, press-fit
Chain
Shimano (CN-HG71)
Wheels
Front Hub
Shimano HB-QC300
Rear Hub
Shimano Nexus 5 SG-C7002-5CD
Rims
Mach1 640 Disc, 21C-622
Tires
Schwalbe Energizer Active Plus PunctureGuard, 50-622
Brakes
Brakes
Shimano BR-MT200/BL-MT201, 180/180 mm
Cockpit
Stem
Ergotec Octopus Ahead 50, 31.8 mm, 90 mm
Handlebar
Ergotec Ladytown, 620 mm
Seat
Saddle
Selle Royal Premium Essenza D
Seatpost
Ergotec Atar, 31.6 mm
Motor & Battery
Motor
Shimano STEPS DU-E6110 center unit, 60Nm
Battery
Shimano BT-E8010, 504Wh (14Ah)
Fit data
Geometry
