Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 45mm -
Fork Zoom
-
Groupset Tourney, Acera -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Trekking 28, AL6061-T4/T6, hydroforming, internal shifting cables
Suspension Fork
ZOOM 141I, 45 mm, 25.4 mm
Drivetrain
Rear Derailleur
Shimano Acera RD-M3020
Front Derailleur
Shimano Altus FD-M313
Shift Levers
Shimano ST-EF500
Cassette
Shimano CS-HG31-8, 11-34T
Crank
Shimano FC-TY301, 48-38-28T
Bottom Bracket
Shimano BB-UN101
Chain
KMC Z8.3
Wheels
Front Hub
Shimano DH-C3000-3N-NT, Hub dynamo
Rear Hub
Shimano FH-QC300
Rims
Tudor 70T, 19-622
Tires
Schwalbe Range Cruiser, K-Guard, 47-622
Brakes
Brakes
Saccon forged V-Brakes
Cockpit
Stem
ID-Project AS-831, adjustable, 31.8 mm, 90 mm
Handlebar
ID-Project Riser Bar HB-RB11L, 640 mm
Grips
Herrmans Lockable Grip Line
Seat
Saddle
Selle Royal RVS Moody
Seatpost
ID-Project SPDC2, 30.9 mm
Fit data
Geometry
