Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Fork RST BLAZE -
Groupset Deore -
Suspension Hardtail -
Motor Shimano 250W 60Nm mid-drive -
Battery Shimano STEPS (down tube) BT-E8010, 36V, 14Ah, 504Wh -
Drivetrain 1 × 10 -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eAdventure 27.5, AL6061-T4 / T6, Shimano STEPS, hydroforming, internal brake & gear cables, semi-integrated battery
Suspension Fork
RST Blaze-MLC, 100 mm, lockout, adjustable preload
Drivetrain
Rear Derailleur
Shimano Deore RD-M5120 SGS
Shift Levers
Shimano STEPS SW-E7000-L / Shimano Deore SL-M4100-R
Cassette
Shimano CS-M4100-10, 11-42T
Crank
Shimano STEPS FC-E6100, 38T
Bottom Bracket
STEPS, press-fit
Chain
Shimano CN-E6090-10
Wheels
Front Hub
Shimano HB-M3050
Rear Hub
Shimano FH-M3050
Rims
Mach1 670, 584-21
Tires
Schwalbe 60-584 (27.5x2.35), Johnny Watts
Brakes
Brakes
Shimano BR-M200 / BL-M201 hydraulic disc brakes 180/180 mm
Cockpit
Stem
Ergotec Crab 2 aluminum, 31.8 mm, safety level 4
Handlebar
Ergotec Low Riser aluminum bar, 700 mm, safety level 4
Seat
Saddle
Selle Royall Premium, Moderate VLS, New Essenza
Seatpost
Ergotec Atar aluminum, 31.6 mm, safety level 4
Motor & Battery
Motor
Shimano STEPS DU-E6100, 36V, 250W, 60Nm, sport
Battery
Shimano STEPS (down tube) BT-E8010, 36V, 14Ah, 504Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 50cm | 54cm |
|---|---|---|---|
| Front Center | 677 mm | 688 mm | 699 mm |
| Top Tube Length | 590 mm | 600 mm | 610 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 460 mm | 500 mm | 540 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 160 mm | 170 mm | 180 mm |
| Chainstay Length | 480 mm | 480 mm | 480 mm |
| Wheelbase | 1152 mm | 1162 mm | 1173 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm |
| Wheels | 650 | 650 | 650 |
