Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 80mm -
Fork Zoom
-
Groupset Tourney -
Suspension Hardtail -
Drivetrain 2 × 8 -
Brakes Shimano Deore Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Hardtail, AL6061-T4/T6, hydroforming, tapered head tube, internal cable routing
Suspension Fork
ZOOM 389A, 80mm, adjustable preload
Drivetrain
Rear Derailleur
Shimano RD-TX800
Front Derailleur
Shimano FD-TY710-2
Shift Levers
Shimano ST-EF505
Cassette
Shimano CS-HG31, 11-34T
Crank
Shimano FC-TY501-2, 46-30T
Bottom Bracket
Shimano BB-UN101
Chain
KMC Z8
Wheels
Front Hub
Shimano HB-TX505, center lock
Rear Hub
Shimano FH-TX505-8, center lock
Rims
Cross X-6, 622-21 x 20.5mm
Tires
Kenda K1153, 54-622 (29x2.10)
Brakes
Brakes
Shimano BR-MT200 / BL-M505 hydraulic disc brakes, 160/160mm
Cockpit
Stem
ID-Project aluminum, 31.8 mm
Handlebar
ID-Project riser bar aluminum, 680mm
Seat
Saddle
Selle Royal Mach
Seatpost
ID-Project aluminum, 30.9 mm
Fit data
Geometry
