Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 60mm -
Fork RST NOVA
-
Groupset Deore, Altus -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Shimano Deore Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Hardtail Touring, AL6061-T4/T6, hydroforming, internal cable routing
Suspension Fork
RST Nova-ML, 60 mm, lockout, adjustable preload
Drivetrain
Rear Derailleur
Shimano Deore, RD-M591SGS
Front Derailleur
Shimano Altus, FD-M370
Shift Levers
Shimano ST-EF505
Cassette
Shimano CS-HG201-9, 9-SPEED, 11-32T
Crank
Shimano FC-M371, 48-36-26T
Bottom Bracket
Shimano BB-UN101
Chain
Shimano CN-HG53
Wheels
Front Hub
Shimano DH-3D37 hub dynamo, QR center lock
Rear Hub
Shimano FH-TX505-8
Rims
Cross x-6, 622-21 x 20.5 mm
Tires
Schwalbe Marathon GT Tour, DualGuard, 47-622 (28x1.75)
Brakes
Brakes
Shimano BR-M200 / BL-M505 hydraulic disc brakes, 180/160 mm
Cockpit
Stem
id-Project aluminum, 90/110 mm extension, 6 ° angle, 31.8mm barbore
Handlebar
id-Project riser bar aluminum, 640mm wide, 15mm rise, 5 ° backsweep, 31.8mm barbore
Grips
Herrmans Lockable Grip Line
Seat
Saddle
Selle Roual Premium, New Essenza H / D, Moderate
Seatpost
id-Project aluminum, size 30.9 mm, length 350 mm, zero offset
Fit data
Geometry
