Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 60mm -
Fork RST NOVA
-
Groupset Deore, Altus -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Hardtail Touring, AL6061-T4/T6, hydroforming, internal cable routing
Suspension Fork
RST Nova-ML, 60 mm, lock out, adjustable preload
Drivetrain
Rear Derailleur
Shimano Deore, RD-M591 SGS
Front Derailleur
Shimano Altus, FD-M370
Shift Levers
Shimano ST-EF505
Cassette
Shimano CS-HG201-9, 11-12-14-16-18-21-24-28-32T
Crank
Shimano FC-M371, 48-36-26T, up to 46 cm- 170 mm, else 175 mm
Bottom Bracket
Shimano BB-UN100
Chain
Shimano CN-HG53
Wheels
Front Hub
Shimano DH-3D37 Dynamo hub, QR center lock
Rear Hub
Shimano FH-TX505
Rims
Cross X-6, 21-622
Tires
Schwalbe Citizen K-Guard, reflective, 42-622
Brakes
Brakes
Shimano BR-MT200/ST-EF505, hydraulic disc brakes, 180/160 mm
Cockpit
Stem
ID-Project, 90mm extension, 31.8 mm, AS-832
Handlebar
ID-Project Riser Bar, 640 mm, HB-RB11L
Seat
Saddle
Selle Bassano L Volare 3-Zone Comfort
Seatpost
ID-Project, 30.9 mm (SP-368)
Fit data
Geometry
