Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 80mm -
Fork Zoom
-
Groupset Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Hardtail, AL6061-T4 / T6, hydroforming, internal gear cables
Suspension Fork
ZOOM 389, 80mm
Drivetrain
Rear Derailleur
Shimano RD-TY300
Front Derailleur
Shimano FD-TY500-TS6
Shift Levers
Shimano ST-EF500
Cassette
Shimano MF-TZ500, 14-28T
Crank
Shimano FC-TY301, 42-34-24T
Bottom Bracket
Shimano BB-UN101
Chain
KMC Z7
Wheels
Front Hub
Joytech aluminum
Rear Hub
Joytech aluminum
Rims
Mach1, 622-19, 19mm
Tires
Kenda K1153, 54-622 (29x2.10)
Brakes
Brakes
Saccon, V-brakes, aluminum
Cockpit
Stem
Ahead 25.4 mm
Handlebar
Riser bar, 640 mm
Seat
Saddle
Sell ??Royal RVS
Seatpost
30.9 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 44cm | 48cm | 52cm |
|---|---|---|---|
| Bottom Bracket Height | 329 mm | 329 mm | 329 mm |
| Front Center | 647 mm | 667 mm | 688 mm |
| Top Tube Length | 580 mm | 600 mm | 620 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1072 mm | 1093 mm | 1113 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm |
| Wheels | 29" | 29" | 29" |
