iGO Electric Outland – Sawback RS 2024
2024 E-bike
Estimate price |
2,897$
Weight | 27.4 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 120mm -
Fork Suntour
-
Groupset Alivio -
Suspension Hardtail -
Motor 500W mid-drive -
Battery 5000mAh SAMSUNG cell, removable with security lock (48V | 15Ah | 720Wh) -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Hydroformed Alloy, 27.5 Hardtail MTB frame, internal cable routing head tube ported, removable down tube battery with security lock
Suspension Fork
SUNTOUR SF-18 27.5” XM34-DS-Boost-LO suspension, 120mm travel, lockout, Thru Axle
Drivetrain
Rear Derailleur
SHIMANO ALIVIO 9-speed
Shift Levers
SHIMANO ALIVIO 9-speed Rapidfire Plus
Cassette
SHIMANO ALIVIO 9-speed 11-36T
Crank
34T with Narrow Wide teeth
Chain
KMC E9-S
Wheels
Rims
27.5”, Dual Wall Alloy, black
Tires
MAXXIS M315 EXO 27.5”x2.4”
Brakes
Brakes
TEKTRO HDE350 Hydraulic Disc
Brake Levers
TEKTRO HDE350 with power cut off switch
Cockpit
Stem
45mm with 3 degree rise, 31.8mm clamp dia.
Handlebar
720mm, 28mm rise, 31.8mm dia.
Grips
VELO, Rubber palm rest, 132mm
Seat
Saddle
SELLE ROYAL Viento
Seatpost
EXA KSP900-1 Dropper Post, 150mm travel (445mm)
Motor & Battery
Motor
iGO DRIVE RS 500W mid motor, 48V
Battery
5000mAh SAMSUNG cell, removable with security lock (48V | 15Ah | 720Wh)
