Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 200mm -
Travel Rear 240mm -
Fork RockShox BoXXer
-
Groupset X01, Truvativ Descendant -
Suspension Full -
Drivetrain 1 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
M16 275 Optimized Layup Carbon Front and Rear Triangle 275” DH Frameset, ISCG 05 Mount, w/ 157 x12 mm spacing, 215 -240 mm travel
Suspension Fork
Rock Shox Boxxer World Cup, 200mm, Gloss Black, 20x110mm
Rear Shock
Rock Shox Super Deluxe Coil World Cup, 250x75mm (SM - 400lb Spring, MD – 450lb Spring, LG – 500lb Spring, XL – 550lb Spring)
Drivetrain
Rear Derailleur
SRAM X01 DH, 7 speed
Front Derailleur
N/A
Shift Levers
SRAM X01 DH, 7 speed
Cassette
SRAM XG-795 10-24, 7 speed
Crank
TruVativ Descendant DH, GXP 83mm, 165mm, 36T
Bottom Bracket
BSA (threaded), 83 mm
Chain
SRAM X1, 11 speed
Chain Guide
E13 LG1
Wheels
Front Hub
DT Swiss FR 1950 CLASSIC 27.5, 110x20 mm front HUB; 157 x 12 mm rear w/XD Driver, 20 mm front
Rear Hub
DT Swiss FR 1950 CLASSIC 27.5, 110x20 mm front HUB; 157 x 12 mm rear w/XD Driver, 20 mm front
Rims
DT Swiss FR 1950
Spokes
DT Swiss
Tires
Front: 27.5x2.5, MINION DHF, FOLDABLE, F60, DH Casing, 3CG, Rear: 27.5X2.4, MINION DHR II, FOLDABLE, F60, DH Casing, 3CG
Brakes
Brakes
Shimano Saint, 203 mm front and rear
Cockpit
Stem
Renthal Integra II Direct Mount 45 mm
Handlebar
Intense Recon DH Alloy 31.8mm – 800mm
Grips
Intense Dual Density Lock-On
Headset
Cane Creek, 40, alloy cartridge, 25 mm of spacers
Seat
Saddle
WTB Volt Team
Seatpost
Intense Recon DH Alloy, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.43 mm | 1.37 mm | 1.34 mm |
| Stack | 586 mm | 591 mm | 597 mm | 606 mm |
| Reach | 390 mm | 412 mm | 435 mm | 451 mm |
| Top Tube Length | 564 mm | 590 mm | 615 mm | 633 mm |
| Seat Tube Angle | 73.3 ° | 73.3 ° | 73.3 ° | 73.3 ° |
| Seat Tube Length | 416 mm | 440 mm | 455 mm | 457 mm |
| Head Tube Angle | 63.5 ° | 63.5 ° | 63.5 ° | 63.5 ° |
| Head Tube Length | 109 mm | 115 mm | 122 mm | 132 mm |
| Chainstay Length | 444 mm | 444 mm | 444 mm | 444 mm |
| Wheelbase | 1193 mm | 1218 mm | 1244 mm | 1264 mm |
| Bottom Bracket Drop | -8916 mm | -10 mm | -10 mm | -10 mm |
| Standover Height | 796 mm | 802 mm | 808 mm | 815 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
M16 PRO completes the Intense M16 model. 3 bikes variations carry this model name so far.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Downhill bikes
According to our calculations, the average cost of a Downhill bike that is reliable is 3391$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Downhill bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2019 and its price was 4999$. In conclusion, this bike price is 47.42% higher than the price of the average Downhill bike.
M16 PRO components
Fork
The fork installed on this bike is the RockShox BoXXer model. The travel on this model is 200mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The M16 PRO has a rear shock with a travel of 240mm. The model Rock Shox Super Deluxe Coil World Cup is the one installed in this bike. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
As for the wheels, Intense M16 PRO 2019, has a 27.5″ aluminum model. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The M16 PRO comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
