Intense TAZER MX ALLOY EXPERT 2024
2024 E-bike
Estimate price |
4,999$
Weight | 26.39 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 160mm -
Travel Rear 155mm -
Fork DVO Diamond
-
Groupset Deore -
Suspension Full -
Motor Shimano 600W 85Nm mid-drive -
Battery BT-EN805-L, for STEPS, 504Wh Battery lock w/ 2 keys -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Tazer Performance Alloy Frame. Alloy top link, internal shift, dropper, post, brake, display unit routing, E*Spec Chainguide mount pattern, flak guard armor, integrated mud guard, 160mm front travel, 155mm rear travel, Universal Derailleur Hanger (UDH), SRAM T-Type compatibility.
Suspension Fork
DVO Diamond E3, Single Crown, 160mm travel
Rear Shock
DVO Jade X E3, Coil, (Does not include Low/High Speed compression adjustment dial) 155mm travel, spring 550lbs SM/MD, 650lbs LG/XL
Drivetrain
Rear Derailleur
Shimano Deore, 11-speed
Shift Levers
Shimano Deore, 11-speed
Cassette
Shimano Deore CS-M5100 11-speed, 10-51T
Crank
Shimano FC-EM600, 34 tooth chainring, 165mm length
Chain
KMC E12-speed
Chain Guide
e*thirteen e*spec Plus
Wheels
Front Hub
INTENSE E-MTN Alloy Hubs
Rear Hub
INTENSE E-MTN Alloy Hubs
Rims
WTB ST i30 TCX 2.0 30mm, 110x15mm, 29" front / WTB ST i35 TCS, 148x12mm, 27.5" rear
Tires
MAXXIS Minion DHR II Maxx Terra 3C ECO+, 29"x2.60" front, 27.5"x2.80" rear
Brakes
Brakes
TRP Trail EVO, HD-M843 / 203mm rotors
Cockpit
Stem
INTENSE 35mm OD x 45mm Length
Handlebar
INTENSE Recon 35 OD x 800mm wide, 30mm rise
Grips
INTENSE Lock-on
Headset
INTENSE ZS49/ZS56
Seat
Saddle
WTB Volt
Seatpost
INTENSE Recon Dropper, length125mm SM/MD / 150mm LG/XL
Motor & Battery
Motor
Shimano EP600 STEPS Motor
Battery
BT-EN805-L, for STEPS, 504Wh Battery lock w/ 2 keys
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM/MD | XL |
|---|---|---|
| Stack Reach Ratio | 1.446 mm | 1.333 mm |
| Bottom Bracket Height | 348 mm | 348 mm |
| Front Center | 777 mm | 831 mm |
| Rake | 42 mm | 48 mm |
| Trail | 132 mm | 125 mm |
| Stack | 632 mm | 641 mm |
| Reach | 437 mm | 481 mm |
| Top Tube Length | 608 mm | 662 mm |
| Seat Tube Angle | 75 ° | 75 ° |
| Seat Tube Length | 420 mm | 470 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° |
| Head Tube Length | 115 mm | 125 mm |
| Chainstay Length | 450 mm | 450 mm |
| Wheelbase | 1226 mm | 1281 mm |
| Bottom Bracket Drop | 17 mm | 17 mm |
| Standover Height | 830 mm | 845 mm |
| Wheels | 29" | 29" |
