Intense TAZER MX ALLOY PRO 2024
2024 E-bike
Estimate price |
6,499$
Weight | 26.42 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 170mm -
Travel Rear 155mm -
Fork Öhlins RXF38
-
Groupset TRP EVO 12 -
Suspension Full -
Motor Shimano 600W 85Nm mid-drive -
Battery BT-EN806, for STEPS, 630Wh Battery lock w/ 2 keys -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Tazer Performance Alloy Frame. Alloy top link, internal shift, dropper, post, brake, display unit routing, E*Spec Chainguide mount pattern, flak guard armor, integrated mud guard, 170mm front travel, 155mm rear travel, Universal Derailleur Hanger (UDH), SRAM T-Type compatibility.
Suspension Fork
Öhlins RXF 38 M2 Fork, Single Crown, 170mm travel, air spring system
Rear Shock
Öhlins TTX22M coil, 155mm travel, spring 548lbs (SM/MD), 640lbs (LG/XL)
Drivetrain
Rear Derailleur
TRP RD-M9050-L EVO 12-speed
Shift Levers
TRP SL-M9050-12R EVO 12-speed
Cassette
Shimano Deore CS-M6100 12-speed, 10-51T
Crank
Shimano FC-M8150, 34 tooth chainring, 165mm length
Chain
KMC E12 Turbo 12-speed
Chain Guide
e*thirteen e*spec Plus
Wheels
Front Hub
INTENSE E-MTN Alloy Hubs
Rear Hub
INTENSE E-MTN Alloy Hubs
Rims
e*thirteen e*spec 30mm, 110x15mm, 29" front / e*thirteen e*spec 35mm, 148x12mm, 27.5" rear
Tires
Pirelli Scorpion E-MTB S, Hyperwall, 29" x 2.60" front / 27.5" x 2.80" rear
Brakes
Brakes
TRP DH-R EVO, HD-M846 / 203mm rotors
Cockpit
Stem
INTENSE 35mm OD x 45mm Length
Handlebar
Renthal Fatbar 35mm diameter 800mm width 30mm Rise
Grips
ODI Elite Flow
Headset
INTENSE ZS49/ZS56
Seat
Saddle
SDG Bel-Air V3
Seatpost
INTENSE Recon Dropper, length125mm (SM/MD) / 150mm (LG/XL)
Motor & Battery
Motor
Shimano EP801 STEPS Motor
Battery
BT-EN806, for STEPS, 630Wh Battery lock w/ 2 keys
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM/MD | XL |
|---|---|---|
| Stack Reach Ratio | 1.457 mm | 1.343 mm |
| Bottom Bracket Height | 348 mm | 348 mm |
| Front Center | 784 mm | 835 mm |
| Rake | 43 mm | 43 mm |
| Trail | 135 mm | 135 mm |
| Stack | 634 mm | 646 mm |
| Reach | 435 mm | 481 mm |
| Top Tube Length | 609 mm | 664 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° |
| Seat Tube Length | 420 mm | 420 mm |
| Head Tube Angle | 64 ° | 64 ° |
| Head Tube Length | 115 mm | 125 mm |
| Chainstay Length | 450 mm | 450 mm |
| Wheelbase | 1233 mm | 1285 mm |
| Bottom Bracket Drop | 17 mm | 17 mm |
| Standover Height | 816 mm | 836 mm |
| Wheels | 29" | 29" |
