Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Groupset microSHIFT Advent X -
Suspension Rigid -
Drivetrain 1 × 10 -
Brakes microSHIFT Advent X Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Renegade Size Specific Design frame geometry, SST Reynolds 520 double-butted chromoly main tubes, tapered head tube for tapered fork, threaded BB shell, 12mm Thru- axle, flat mount chain stay disc brake mounts, down tube mounted full cable housing, internal dropper post ready, 3 waterbottle mounts, TT mounts, rack and fender eyelets.
Suspension Fork
Jamis Adventure ECO monocoque carbon composite, 12mm Jamis MTS (Modular Thru-axle System) with stainless interface and carbon dropouts, tapered steerer with 1.5” hollow formed crown, flat mount disc brakes with internal cable routing, exposed fender, lowrider and 3 water bottle eyelets
Drivetrain
Rear Derailleur
MicroShift AdventX RD-M6205AM with Active Motion RD+ with clutch
Shift Levers
MicroShift AdventX 10-speed Shifter/Brake and Dropper
Cassette
MicroShift CS-H104, 10-speed, 11-48
Crank
ProWheel 1x, 40T, 165mm (48), 170mm (51/54/56) 175mm (58/61)
Bottom Bracket
FSA sealed cartridge, 68 x 110.5mm
Chain
KMC X10
Pedals
N/A
Wheels
Rims
WTB ST i23 TCS 2.0 (UST Tubeless Compliant System) disc rims, 32H, Joytec alloy 6-bolt hubs, 14g stainless steel spokes and front 12mm/rear 12×142 thru-axle with Switch Lever
Tires
WTB Riddler Comp 700CX37C, 30tpi Casing, Wire Bead (48-61) WTB BYWAY 650CX40C, 30tpi Casing, Wire Bead (44)
Brakes
Brakes
Tektro Lyra MD-C510 mechanical cable actuated disc flat mount brake with 160mm wave rotors and Microshift AdventX levers
Cockpit
Stem
Ritchey 4-AXIS Stem 6°x60mm (48-51), 70mm (54-56), 80mm (58/61)
Handlebar
Ritchey Baquiano Comp, 6061 aluminum, 73 reach, 118 ergonomic drop with 12ç flare, 31.8 x 400 (44) 420 (48-51) 440mm (54-56), 460mm (56-61)
Headset
FSA No.57E/42/CUP Internal headset with lower cup, 1.5 – 1 1/8”
Seat
Saddle
Selle Royal SRX Gravel Saddle with CROMO rails
Seatpost
Jamis Road, micro-adjust, 27.2 x 350mm cromo seat pin
