Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Suspension Rigid -
Drivetrain Single Speed -
Brakes Shimano Coaster
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Diamond frame design with 6061 aluminum oversized tubing, sloping top tube design, alloy kickstand, and painted steel chainguard
Suspension Fork
Oversized hi-tensile steel tubular unicrown with leading dropout and fender boss
Drivetrain
Rear Derailleur
N/A
Shift Levers
N/A
Cassette
Shimano 18T
Crank
Forged alloy crank, 170mm, with 44T alloy compact disc chainring
Bottom Bracket
Sealed cartridge BB with alloy cups & sheath, 68 x 116mm
Chain
Taya 410H-GST, rustless
Pedals
Cruiser platform with heat-treated axles and rustless bushings
Wheels
Rims
Alex X303 36H silver anodized alloy rims with alloy double-sealed front and Shimano CB rear hubs, heavy- duty 12 gauge stainless steel spokes
Tires
CST Metropolitan Palm Bay, 26” x 2.35
Brakes
Brakes
Shimano coaster brake
Cockpit
Stem
Alloy hi-rise, 150mm quill, 100mm extension, with removeable 2-bolt cap
Handlebar
Jamis Cruise-control comfort bar
Grips
Kraton comfort type with full length,extra-thick, foam bar pads
Headset
Internal cup, threaded, 1 1/8”
Seat
Saddle
Taxi design with extra padding, extra-thick vinyl cover, heavy-duty strut rails & double-loop springs with bag loops
Seatpost
Alloy pillar style, 26.8 x 300mm, with plugged top, welded seat collar with chromoly QR
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM | SM | 17" | 19" | SM | 21" |
|---|---|---|---|---|---|---|---|
| Bottom Bracket Height | 172 mm | 269 mm | 285 mm | 277 mm | 277 mm | 277 mm | 277 mm |
| Rake | 25 mm | 25 mm | 35 mm | 35 mm | 35 mm | 35 mm | 35 mm |
| Top Tube Length | 385 mm | 483 mm | 523 mm | 586 mm | 595 mm | 596 mm | 614 mm |
| Seat Tube Angle | 71.1 ° | 69 ° | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Seat Tube Length | 203 mm | 254 mm | 381 mm | 432 mm | 483 mm | 457 mm | 533 mm |
| Head Tube Angle | 71.1 ° | 71 ° | 68 ° | 69 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 110 mm | 125 mm | 110 mm | 150 mm |
| Chainstay Length | 320 mm | 385 mm | 445 mm | 487 mm | 487 mm | 487 mm | 487 mm |
| Wheelbase | 730 mm | 874 mm | 1015 mm | 1091 mm | 1090 mm | 1090 mm | 1109 mm |
| Standover Height | 439 mm | 512 mm | 572 mm | 736 mm | 757 mm | 620 mm | 803 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" | 26" | 26" |
