kalkhoff ENTICE 5+ ADVANCE BELT Wave 2024
2024 E-bike
Estimate price |
6,536$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 51mm -
Fork Suntour MOBIE
-
Suspension Hardtail -
Motor Bosch 600W 85Nm mid-drive -
Battery Bosch PowerTube Li-Ion (800 Wh),Bosch PowerTube Li-Ion (600 Wh) -
Drivetrain Belt Drive -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
SR Suntour Mobie34, 110x15 mm thru axle
Drivetrain
Shift Levers
Hub
Cassette
Gates Carbondrive CDX
Crank
Aluminium
Chain
Gates Carbondrive CDX
Pedals
MTB Flat, Aluminium, mit Reflektor
Wheels
Rims
Aluminium, Hohlkammer,Aluminium, hollow section
Tires
Schwalbe Smart Sam Black Reflex 57-622,Schwalbe Smart Sam Bronze Reflex 57-622
Brakes
Brakes
hydraulic disc brake
Cockpit
Stem
Cockpit 2.0, adjustable, 70 mm
Handlebar
Allroad Riser
Seat
Saddle
Selle Royal Vivo
Seatpost
Aluminium, gefedert,Aluminium, suspension
Motor & Battery
Motor
Bosch Performance Line CX Smart System
Battery
Bosch PowerTube Li-Ion (800 Wh),Bosch PowerTube Li-Ion (600 Wh)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.633 mm | 1.608 mm | 1.613 mm | 1.612 mm | 1.61 mm |
| Stack | 653 mm | 653 mm | 663 mm | 672 mm | 681 mm |
| Reach | 400 mm | 406 mm | 411 mm | 417 mm | 423 mm |
| Top Tube Length | 600 mm | 606 mm | 614 mm | 623 mm | 631 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 130 mm | 130 mm | 140 mm | 150 mm | 130 mm |
| Wheelbase | 1206 mm | 1212 mm | 1221 mm | 1231 mm | 1241 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Front Travel | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 |
