kalkhoff ENTICE 7+ ADVANCE Diamond 2024
2024 E-bike
Estimate price |
7,339$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 44mm -
Fork Suntour MOBIE
-
Groupset CUES -
Suspension Hardtail -
Motor Bosch 600W 85Nm mid-drive -
Battery Bosch PowerTube Li-Ion (800 Wh) -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
SR Suntour Mobie36 Air, 110x15 mm thru axle
Drivetrain
Rear Derailleur
11-G Shimano Cues
Cassette
Shimano Cues Linkglide
Crank
Aluminium
Chain
Shimano CN-LG500
Pedals
MTB Flat, Aluminium, mit Reflektor
Wheels
Rims
Aluminium, Hohlkammer
Tires
Schwalbe Jonhny Watts 365 Performance Reflex, 60-622,Schwalbe Jonhny Watts 365 Performance Reflex, 60-584
Brakes
Brakes
hydraulic disc brake
Cockpit
Stem
Cockpit 2.0, adjustable, 65mm
Handlebar
Allroad Riser
Seat
Saddle
Selle Royal ON
Seatpost
Absenkbar
Motor & Battery
Motor
Bosch Performance Line CX Smart System
Battery
Bosch PowerTube Li-Ion (800 Wh)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.535 mm | 1.535 mm | 1.545 mm |
| Stack | 631 mm | 631 mm | 641 mm |
| Reach | 411 mm | 411 mm | 415 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Head Tube Angle | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 140 mm | 150 mm | 150 mm |
| Wheelbase | 1235 mm | 1235 mm | 1242 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm |
| Front Travel | 44 mm | 44 mm | 44 mm |
| Wheels | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
