kalkhoff ENTICE L SEASON Diamond 2024
2024 E-bike
Estimate price |
3,440$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 46mm -
Fork Suntour XCM
-
Groupset CUES -
Suspension Hardtail -
Motor Bosch 600W 55Nm mid-drive -
Battery Bosch CompactTube Li-Ion 36 V / 1 1 Ah (400 Wh) -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Suntour XCM32, blockable
Drivetrain
Rear Derailleur
9-G Shimano Cues
Shift Levers
Derailleur
Cassette
Shimano Cues Linkglide
Crank
Aluminium
Chain
Shimano CN-LG500
Pedals
Comfort, Kunststoff
Wheels
Rims
Rodi TRYP25, doppelt geöst
Tires
Schwalbe Smart Sam 57-584,Schwalbe Smart Sam 57-584
Brakes
Brakes
hydraulic disc brake
Cockpit
Stem
Aluminium, adjustable
Handlebar
Allroad Riser
Seat
Saddle
Selle Royal Vivo
Seatpost
Aluminium, starr
Motor & Battery
Motor
Bosch Performance Line SX Smart System
Battery
Bosch CompactTube Li-Ion 36 V / 1 1 Ah (400 Wh)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.636 mm | 1.63 mm | 1.627 mm | 1.621 mm |
| Stack | 648 mm | 657 mm | 667 mm | 676 mm |
| Reach | 396 mm | 403 mm | 410 mm | 417 mm |
| Top Tube Length | 595.6 mm | 604.5 mm | 614.5 mm | 624.5 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 160 mm | 170 mm | 180 mm | 190 mm |
| Wheelbase | 1127 mm | 1144 mm | 1148 mm | 1158 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Front Travel | 46 mm | 46 mm | 46 mm | 46 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
