Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 50mm -
Fork Suntour
-
Groupset Tourney -
Suspension Hardtail -
Drivetrain Internally Geared Hub -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS Aluminium alloy monotube 28
Suspension Fork
SR SUNTOUR CR-8V, 50 mm, coil spring (threaded steerer)
Drivetrain
Shift Levers
SHIMANO ST-EF500-8 EZ-fire Plus
Cassette
SHIMANO CS-HG31-8 (11-34)
Crank
SHIMANO TY501 (48x38x28T) - length 170 mm
Bottom Bracket
cartridge (120 mm)
Chain
KMC Z8 (116 links)
Pedals
NonSlip - plastic
Wheels
Front Hub
SHIMANO Dynamo Nexus C3000 / KLS Drive (36 holes)
Rear Hub
SHIMANO Dynamo Nexus C3000 / KLS Drive (36 holes)
Rims
KLS Draft 622x21 (36 holes / eyelets)
Spokes
steel
Tires
MICHELIN Protek BR 42-622 (700x40C) ReflectiveLine
Brakes
Brakes
TEKTRO V-brake
Brake Levers
SHIMANO ST-EF500-8 EZ-fire Plus
Cockpit
Stem
KALLOY adjustable - diam 25.4 mm / bar bore 25.4 mm / length 90 mm
Handlebar
steel RiseBar - diam 25.4 mm / rise 70 mm / width 630 mm
Grips
KLS Wave 2Density ergonomic
Seat
Saddle
SELLE ROYAL Freedom Royalgel
Seatpost
KALLOY suspension - diam 27.2 mm / length 350 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Wheels | 700 | 700 |
