Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 3 × 10 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS Tour Profile - internal routing, integrated kickstand mount
Suspension Fork
SR SUNTOUR NEX-E25 NLO, 63 mm, coil spring
Drivetrain
Rear Derailleur
SHIMANO Deore XT T8000 (direct mount)
Front Derailleur
SHIMANO Deore T6000 (34.9 mm)
Shift Levers
SHIMANO Deore SL-M6000 Rapidfire Plus
Cassette
SHIMANO CS-HG50-10 (11-36T)
Crank
SHIMANO T521 Hollowtech Octalink (48x36x26T) - length 175 mm
Bottom Bracket
SHIMANO BB-ES300 Octalink
Chain
KMC X10 EL (114 links)
Pedals
alloy
Wheels
Front Hub
SHIMANO Dynamo 3D37 / SHIMANO TX505 Disc Center Lock (32 holes)
Rear Hub
SHIMANO Dynamo 3D37 / SHIMANO TX505 Disc Center Lock (32 holes)
Rims
KLS Draft Disc 622x21 (32 holes / eyelets)
Spokes
steel
Tires
MICHELIN Protek BR 42-622 (700x40C) ReflectiveLine
Brakes
Brakes
SHIMANO MT200 Hydraulic Disc
Brake Levers
SHIMANO BL-MT200
Cockpit
Stem
PROMAX a-head adjustable - diam 28.6 mm / bar bore 31.8 mm / length 105 mm
Handlebar
alloy RiseBar - diam 31.8 mm / width 640 mm
Grips
KLS Wave 2Density ergonomic
Seat
Saddle
SELLE ROYAL Lookin Visual Royalgel
Seatpost
KALLOY suspension - diam 30.9 mm / length 350 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
