Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Tourney, Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS Crosslite Lady
Suspension Fork
SR SUNTOUR NEX HLO DS, 63 mm, coil / Speed Lockout
Drivetrain
Rear Derailleur
SHIMANO Altus M370 (direct mount)
Front Derailleur
SHIMANO TY710 (31.8 mm)
Shift Levers
SHIMANO Altus SL-M310 Rapidfire Plus
Cassette
SHIMANO CS-HG200-8 (12-32T)
Crank
SHIMANO TY501 (48x38x28T) - length 170 mm (S), 175 mm (M)
Bottom Bracket
cartridge (122 mm)
Chain
KMC Z8 (114 links)
Pedals
alloy
Wheels
Front Hub
KLS Firework Disc (32 holes)
Rear Hub
KLS Firework Disc (32 holes)
Rims
KLS Draft Disc 622x21 (32 holes / eyelets)
Spokes
stainless steel
Tires
INNOVA 44-622 (700x42C)
Brakes
Brakes
TEKTRO Hydraulic Disc or KLS 1600 Hydraulic Disc
Brake Levers
TEKTRO or KLS 1600
Cockpit
Stem
KLS CRX 70 adjustable - diam 28.6 mm / bar bore 31.8 mm / length 95 mm
Handlebar
KLS CRX 70 RiseBar - diam 31.8 mm / rise 25 mm / width 640 mm
Grips
KLS Token 2Density
Seat
Saddle
KLS ComfortLine
Seatpost
KALLOY - diam 27.2 mm / length 350 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Wheels | 700 | 700 |
