Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 50mm -
Fork Suntour M 3010
-
Groupset Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS Crosslite
Suspension Fork
SR SUNTOUR M3010 P, 50 mm, coil spring
Drivetrain
Rear Derailleur
SHIMANO TY300 (direct mount)
Front Derailleur
SHIMANO TY710 (31.8 mm)
Shift Levers
SHIMANO ST-EF41-7 EZ-fire Plus
Cassette
SHIMANO CS-HG200-7 (12-32T)
Crank
PROWHEEL (48x38x28T) - length 170 mm
Bottom Bracket
cartridge (124.5 mm)
Chain
KMC Z7 (114 links)
Pedals
plastic
Wheels
Front Hub
alloy / SHIMANO TY500-7 (32 holes)
Rear Hub
alloy / SHIMANO TY500-7 (32 holes)
Rims
KLS Draft 622x21 (32 holes / eyelets)
Spokes
steel
Tires
INNOVA 44-622 (700x42C)
Brakes
Brakes
APSE V-brake
Brake Levers
SHIMANO ST-EF41-7 EZ-fire Plus
Cockpit
Stem
KALLOY - diam 28.6 mm / bar bore 25.4 mm / 15° / length 75 mm (S), 90 mm (M - L)
Handlebar
steel RiseBar - diam 25.4 mm / rise 30 mm / width 640 mm (S - M), 660 mm (L)
Grips
KLS Token
Seat
Saddle
KLS CrossLine
Seatpost
steel - diam 27.2 mm / length 330 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
