Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Tourney -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS Crosslite
Suspension Fork
SR SUNTOUR NEX HLO P, 63 mm, coil / Speed Lockout
Drivetrain
Rear Derailleur
SHIMANO TX800 (direct mount)
Front Derailleur
SHIMANO TY710 (31.8 mm)
Shift Levers
SHIMANO ST-EF500-8 EZ-fire Plus
Cassette
SHIMANO CS-HG200-8 (12-32T)
Crank
SHIMANO TY301 (48x38x28T) - length 170 mm (S), 175 mm (M - XL)
Bottom Bracket
cartridge (122 mm)
Chain
KMC Z8 (114 links)
Pedals
plastic
Wheels
Front Hub
alloy (32 holes)
Rear Hub
alloy (32 holes)
Rims
KLS Draft 622x21 (32 holes / eyelets)
Spokes
steel
Tires
INNOVA 44-622 (700x42C)
Brakes
Brakes
TEKTRO V-brake
Brake Levers
SHIMANO ST-EF500-8 EZ-fire Plus
Cockpit
Stem
KALLOY - diam 28.6 mm / bar bore 25.4 mm / 15° / length 75 mm (S), 90 mm (M - L), 105 mm (XL)
Handlebar
alloy RiseBar - diam 25.4 mm / width 640 mm (S - M), 660 mm (L - XL)
Grips
KLS Token 2Density
Seat
Saddle
KLS CrossLine
Seatpost
KALLOY - diam 27.2 mm / length 350 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
