Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NEX
-
Groupset Nexus, Shimano -
Suspension Hardtail -
Motor Shimano 250W 40Nm mid-drive -
Battery SHIMANO BT-E8010, 504Wh / capacity 14Ah -
Drivetrain Internally Geared Hub -
Brakes Coaster
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS e-FRAME City Aluminium alloy monotube, semi-integrated battery, tapered HT, integrated kickstand mount
Suspension Fork
SR SUNTOUR NEX-E25 NLO, 63mm, coil spring
Drivetrain
Shift Levers
SHIMANO Nexus SL-C6000-8 Revoshift
Cassette
for internal hub 18T
Crank
SHIMANO E5000 (38T) - length 170mm
Chain
KMC Z1 (102 links)
Pedals
plastic
Wheels
Front Hub
SHIMANO TX505 / SHIMANO Nexus C6001-8 Disc Center Lock / coaster brake (32 holes)
Rear Hub
SHIMANO TX505 / SHIMANO Nexus C6001-8 Disc Center Lock / coaster brake (32 holes)
Rims
KLS Draft Disc 622x21 (32 holes)
Spokes
stainless steel black
Tires
IMPAC Streetpac 47-622 (28x1.75) ReflectiveLine
Brakes
Brakes
SHIMANO MT200 Hydraulic Disc
Brake Levers
SHIMANO BL-MT200
Disk Rotors
160mm front / 160mm rear
Cockpit
Stem
PROMAX a-head adjustable - diam 28.6mm / bar bore 31.8mm / length 85mm (S), 105mm (M)
Handlebar
KALLOY RiseBar - diam 31.8mm / width 640mm
Grips
KLS Wave 2Density ergonomic
Seat
Saddle
SELLE ROYAL Freedom Royalgel
Seatpost
KALLOY suspension - diam 30.9mm / length 300mm (S), 350mm (M)
Motor & Battery
Motor
SHIMANO STEPS E5000, 36V
Battery
SHIMANO BT-E8010, 504Wh / capacity 14Ah
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Wheels | 700 | 700 |
Model Overview
ESTIMA 50 504Wh belongs to the Kellys E Estima model. There are 8 e-bikes that carry this model name.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
General Urban e-bikes average price
If you want an acceptable General Urban e-bike you should know that the average price is 2098$. However, paying less money than this amount doesn’t mean that you couldn’t get a great General Urban e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
ESTIMA 50 504Wh components
Fork
The ESTIMA 50 504Wh comes factory-installed with the SunTour NEX fork. This has a travel range of 63mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The wheels on ESTIMA 50 504Wh are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The ESTIMA 50 504Wh has Coaster brakes. These brakes are pretty efficient, and they’re not so pricey. However, they have flaws, especially if the chain falls off.
