Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Travel Front 100mm -
Fork RockShox SID Select+
-
Groupset XT -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Shimano XT Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS iCAD Carbon Pro 29", tapered HT, internal routing, 12x148 mm Boost thru axle
Suspension Fork
ROCK SHOX SID Select+ (29") Boost, 100 mm, DebonAir / Charger 2 RL / OneLoc Remote Lockout / Maxle Stealth 15 mm thru axle
Drivetrain
Rear Derailleur
SHIMANO Deore XT M8100 (direct mount)
Shift Levers
SHIMANO Deore XT SL-M8100-IR Rapidfire Plus (I-spec EV)
Cassette
SHIMANO CS-M7100-12 (10-51T)
Crank
SHIMANO Deore XT M8100-1 Hollowtech II (34T) - length 175 mm
Bottom Bracket
SHIMANO Press-Fit BB71-41A
Chain
KMC X12 (114 links)
Pedals
plastic
Wheels
Front Hub
MAVIC Crossmax 29" or NOVATEC Disc (32 holes)
Rear Hub
MAVIC Crossmax 29" or NOVATEC Disc (32 holes)
Rims
MAVIC Crossmax 29" alebo MAVIC X 1025 (32 holes)
Spokes
stainless steel black
Tires
Front: SCHWALBE Racing Ray Performance 57-622 (29"x2.25) folding, Rear: SCHWALBE Racing Ralph Performance 57-622 (29"x2.25) folding
Brakes
Brakes
SHIMANO Deore XT M8100 Hydraulic Disc
Brake Levers
SHIMANO Deore XT BL-M8100
Cockpit
Stem
KLS Ultimate - diam 28.6 mm / bar bore 31.8 mm / 7° / length 80 mm (M), 90 mm (L)
Handlebar
KLS Ultimate FlatBar - diam 31.8 mm / width 720 mm
Grips
KLS Poison OneLockon
Seat
Saddle
fi´zi:k Antares R7 S-alloy rails
Seatpost
KLS Ultimate - diam 30.9 mm / length 400 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Wheels | 29" | 29" |
