Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Nexus -
Suspension Rigid -
Drivetrain Internally Geared Hub -
Brakes Tektro Coaster
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS Aluminium alloy monotube 24
Suspension Fork
hi-ten steel unicrown (threaded steerer)
Drivetrain
Shift Levers
SHIMANO Nexus SL-3S41E Revoshift
Cassette
SHIMANO for internal hub 20T
Crank
PROWHEEL (38T) - length 152 mm
Bottom Bracket
cartridge (117.5 mm)
Chain
KMC Z6 (94 links)
Pedals
NonSlip - plastic
Wheels
Front Hub
alloy / SHIMANO Nexus 3C41 Inter-3 (36 holes)
Rear Hub
alloy / SHIMANO Nexus 3C41 Inter-3 (36 holes)
Rims
KLS Wasper 507x19 (36 holes)
Spokes
steel
Tires
MITAS Walrus 47-507 (24x1.75x2) ReflectiveLine
Brakes
Brakes
TEKTRO V-brake / SHIMANO coaster brake
Brake Levers
APSE
Cockpit
Stem
alloy - diam 22.2 mm / 30° / length 40 mm
Handlebar
steel - diam 25.4 mm / width 660 mm
Grips
3Density ergonomic
Seat
Saddle
KLS DriveLine Junior
Seatpost
steel - diam 27.2 mm / length 300 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 355 mm |
|---|---|
| Wheels | 24" |
