Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 50mm -
Fork Suntour XCT
-
Groupset Tourney, Altus -
Suspension Hardtail -
Drivetrain 1 × 7 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS Alutec RRC MTB 24 - Race Ready Concept
Suspension Fork
SR SUNTOUR XCT (24), 50 mm, coil spring
Drivetrain
Rear Derailleur
SHIMANO TX800 (direct mount)
Shift Levers
SHIMANO SL-M310 Rapidfire Plus
Cassette
SHIMANO CS-HG200-7 (12-32T)
Crank
PROWHEEL (36T) - length 152 mm
Bottom Bracket
cartridge (126 mm)
Chain
KMC Z7 (102 links)
Pedals
plastic
Wheels
Front Hub
KT Disc (32 holes)
Rear Hub
KT Disc (32 holes)
Rims
KLS Draft Disc 507x19 (32 holes)
Spokes
steel black
Tires
MITAS Winner 50-507 (24x1.95)
Brakes
Brakes
C-STAR CX7 Mechanical Disc
Brake Levers
APSE
Cockpit
Stem
PROMAX - diam 31.8 mm / length 45 mm
Handlebar
KLS Active RiseBar - diam 31.8 mm / rise 18 mm / width 600 mm
Grips
KLS Advancer
Seat
Saddle
KLS DriveLine Junior
Seatpost
KALLOY - diam 27.2 mm / length 300 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 315 mm |
|---|---|
| Wheels | 24" |
