Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 63mm -
Fork Suntour M 3010
-
Groupset Tourney -
Suspension Hardtail -
Drivetrain Internally Geared Hub -
Brakes Tektro Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS Aluminium alloy MTB 26
Suspension Fork
SR SUNTOUR M3010 (26), 63 mm, coil spring
Drivetrain
Shift Levers
SHIMANO ST-EF41-7 EZ-fire Plus
Cassette
SHIMANO CS-HG200-7 (12-32T)
Crank
PROWHEEL (42x34x24T) - length 152 mm
Bottom Bracket
cartridge (120 mm)
Chain
KMC Z7 (106 links)
Pedals
plastic
Wheels
Front Hub
SHIMANO Dynamo Nexus C3000 / SHIMANO TY500-7 (32 holes)
Rear Hub
SHIMANO Dynamo Nexus C3000 / SHIMANO TY500-7 (32 holes)
Rims
KLS Draft 559x21 (32 holes)
Spokes
steel black
Tires
INNOVA 54-559 (26x2.0)
Brakes
Brakes
TEKTRO V-brake
Brake Levers
SHIMANO ST-EF41-7 EZ-fire Plus
Cockpit
Stem
KALLOY - diam 28.6 mm / length 60 mm
Handlebar
steel RiseBar - diam 25.4 mm / width 580 mm
Grips
kraton 2Density
Seat
Saddle
KLS DriveLine Junior
Seatpost
KALLOY - diam 27.2 mm / length 300 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 340 mm |
|---|---|
| Wheels | 26" |
