Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Deore -
Suspension Rigid -
Drivetrain 1 × 10 -
Brakes Tektro Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS Aluminium alloy MTB 26
Suspension Fork
Aluminium alloy
Drivetrain
Rear Derailleur
SHIMANO Deore M6000 (direct mount)
Front Derailleur
chain guide
Shift Levers
SHIMANO Deore SL-M6000-R Rapidfire Plus
Cassette
SHIMANO CS-HG500-10 (11-42T)
Crank
PROWHEEL (30T) - length 155 mm
Bottom Bracket
cartridge (113 mm)
Chain
KMC X10 EL (108 links)
Pedals
plastic
Wheels
Front Hub
alloy / SHIMANO T3000 (32 holes)
Rear Hub
alloy / SHIMANO T3000 (32 holes)
Rims
KLS Draft 559x21 (32 holes)
Spokes
steel black
Tires
SCHWALBE CX Comp, K-Guard 50-559 (26x2.0)
Brakes
Brakes
TEKTRO V-brake
Brake Levers
APSE
Cockpit
Stem
PROMAX - diam 31.8 mm / length 45 mm
Handlebar
KLS Active RiseBar - diam 31.8 mm / rise 18 mm / width 600 mm
Grips
kraton 2Density
Seat
Saddle
KLS DriveLine Junior
Seatpost
KALLOY - diam 27.2 mm / length 300 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 340 mm |
|---|---|
| Wheels | 26" |
